Syscal Pro

Syscal Pro
Syscal Pro

The Syscal Pro is an all-in-one multinode resistivity and induce polarization sounding and profiling system for environmental and engineering geophysical studies. The Syscal Pro gathers a 10 channels receiver and a 250 W internal transmitter which make it the more powerful system of the Syscal range.

Compact, easy-to-use and field proof, the Syscal Pro measures both resistivity and chargeability. It is ideal for environmental and civil engineering applications such as depth-to-rock determination, weathered bedrock mapping. With a maximal output voltage of 2000Vpp, the Syscal Pro is very adapted to detect deep fault in fractured aquifers or to characterize the depths and thickness of the groundwater aquifers.

Several options are available with the Syscal Pro such as the Fullwave mode to record complete time series of measured voltages during an acquisition and the Remote mode that allow for controlling automatically the Syscal Pro through a PC for monitoring purposes.

Several additional accessories are also available to use the Syscal Pro to increase the transmitter power to 1200 W, to perform measurements in borehole, to test the 12V batteries, to communicate via Bluetooth or to upload data on a SD card.

Software

Download
pdf

Prosys II

Resistivity data management
Download
pdf

Electre Pro

Sequence management for Multi-Electrode units
Download
pdf

Fieldview

Real time display of apparent resistivity pseudo section and data quality control
Download
pdf

Comsys Pro

Remote control and data management
Download
pdf

Fullwave viewer

FullWaveViewer is a software allowing to transfer, display and process a time series IP data
Download
pdf

Sysmar

Remote control Acquisition for continuous marine or land  survey

Characteristics

Transmitter

Voltage:

0 - 2000 Vpp

Current:

0 - 2500 mA

Power:

Auto controled Internal 250W DC/DC converter,
and 1200W with external AC/DC

Battery:

internal battery or external 12V

Receiver

Pulse duration:

250ms, 500ms, 1s, 2s, 4s, or 8s

Channels:

10 true differential inputs

Input Impedance:

100 MOhms

Input Voltage:

15V, automatic gain, input protection 1000V

1 µV / 0.2%

Resolution / Accuracy:

GPS:

GPS input for coordinates and synchronisation

Readings:

Resistivity, self-potential, induced polarisation (up to 20 windows), quality control and optional full waveform

Noise Rejection:

power line rejection, SP linear drift correction.

Storage:

44800 readings, up to 8 hours full waveform, stored on solid state memory

Dimensions

( L x W x H)

31x23x31cm Fiber glass casing, weather proof

weight:

11Kg with internal RX & TX batteries

Operating Temp.:

-20 to +70°C
